Description
The VIVID TREAD 1260YZ is a powerful 12x60W RGBW tilting pixel bar built for stages, concerts, discos, night clubs, churches, weddings, and theatres.
Twelve 60W 4-in-1 RGBW LEDs deliver up to 14,400 lumens at a maximum fixture power of 750W. Infinite RGBW color mixing produces 16.7 million colors, with smooth 0-100% 16-bit dimming and a variable strobe from 0-25 FPS.
The motorized linear zoom adjusts the beam from a tight 4.5-degree spot to a wide 35.5-degree wash, while the 220-degree smooth tilt with X/Y intelligent error correction and 8/16-bit movement delivers fast, precise positioning.
Control is fully flexible: DMX512 with 18, 24, 32, or 56-channel modes (56-channel mode gives per-pixel control of all 12 emitters), plus Auto, Master/Slave, and Sound-activated programs.
The 1.8-inch rotatable TFT LCD display with 4 control buttons makes addressing and setup quick. Connections include 3-pin and 5-pin XLR DMX IN/OUT and PowerCON True1 power IN/OUT, running on AC 100-240V 50/60Hz. Forced cooling with temperature control protects the black housing. The fixture is IP20 rated for indoor use in ambient temperatures from -20C to 40C.
Specifications:
- 12 x 60W 4-in-1 RGBW LEDs
- Output: up to 14,400 lm; max fixture power 750W
- Motorized linear zoom: 4.5 to 35.5 degrees
- Tilt: 220-degree smooth tilt, X/Y intelligent error correction, 8/16-bit movement
- Control: DMX512 18/24/32/56CH (56CH = per-pixel control of all 12 emitters); Auto, Master/Slave, Sound
- Dimming: 0-100% 16-bit; strobe 0-25 FPS
- Color: RGBW infinite color mixing, 16.7M colors
- Display: 1.8-inch rotatable TFT LCD, 4 control buttons
- Connectors: 3-pin + 5-pin XLR DMX IN/OUT; PowerCON True1 power IN/OUT; AC 100-240V 50/60Hz
- Cooling: forced cooling with temperature control; black housing
- Rating: IP20 indoor use; ambient -20C to 40C
- Dimensions: 1080 x 140 x 330 mm; weight: 22 kg
Ideal for DJs, venues, churches, and event producers who need a bright, flexible pixel bar with real tilt and zoom.
Huxky FX policy: 1-year warranty. 30-day returns on unopened products; customer pays return shipping.
Tech Specs
Shipping & Return
Shipping
Orders are fulfilled from our warehouse in El Monte, California. We currently ship within the United States only. Standard shipping is FREE and typically arrives within 3–5 business days. You will receive tracking information by email once your order ships.
Returns & Exchanges
Changed your mind? You have 30 days from the date of delivery to return your item for a refund. Items must be unopened and in their original packaging and condition. To start a return, contact us through our Contact page. Customers are responsible for return shipping costs. Once we receive and inspect your return, your refund will be issued to your original payment method.
Warranty
All Huxky FX products are covered by a 1-year warranty against defects in materials and workmanship from the date of purchase. If your product fails under normal use within the warranty period, contact us and we will repair or replace it. This warranty does not cover damage from misuse, accidents, or unauthorized modifications.
